Overview of the Quiqlite QuiqLiteX1 Tactical LED Light | QX1RW3
The Quiqlite QuiqLiteX1 Tactical LED Light gives you reliable hands-free light for duty tasks when you need both hands free. Use QX1RW3 for red and white output so you can write reports, check gear, or work a scene while protecting night vision. You clip it to a uniform shirt pocket, MOLLE webbing, or thicker gear mounts, then aim the beam where you need it.
The housing uses high-strength German nylon, and the light includes a stainless steel adjustable arm that also works as a heat sink to help extend LED life. Images show a low-profile black body with an anti-glare visor, dual LEDs, and a single multi-function on and off button.
Smart Switch control lets you cycle modes and brightness levels at 5, 75, and 150 lumens, with lumen memory so it starts at your last setting. A 5-lumen moonlight mode supports low-light work without washing out your vision. You also get a continuous safety strobe for visibility and signaling. Recharge with the built-in Type-C port for simple, modern charging.
Key Features
-
Output Levels: 5, 75, and 150 lumens with lumen memory
-
Moonlight Mode: 5 lumens, up to 40 hours runtime
-
Medium Mode: 75 lumens, about 4 hours runtime
-
High Mode: 150 lumens, about 2 hours runtime
-
Safety Strobe: 150 lumens continuous strobe (no auto shutoff)
-
Tactical Mode: If the second press is within 2 seconds, you can turn the colored LED off without toggling past white
-
Boost Mode: Quick double press to boost from 5 or 75 up to 150 lumens, double press again to reduce
-
Auto Off Timer: 10-minute auto off timer (applies during boost use)
-
Housing: Nylon and stainless steel construction (German nylon housing)
-
Adjustable Arm: 180-degree adjustable stainless steel arm and heat sink
-
Optics Control: Anti-glare visor helps reduce back-glare
-
Mounting: Removable 360-degree rotating magnetic QuiqClip
-
Mount Thickness: QuiqClip reattaches for thicker mounting up to about 1 inch
-
Charging Port: Type-C USB port on the side
-
Charge Indicators: Charging shows steady red, charged shows flashing red
-
Charging Requirements: Use a Type-C source with at least 5 volts output
-
Charge Time: About 2 hours, up to 2.5 hours or less depending on power source
-
Low Battery Warning: At about 10 percent remaining, it flashes twice every two minutes (about 10 minutes left)
-
Battery: One QuiqLiteX lithium battery included, part number 052042
-
Size and Weight: Length 3 inches, width 0.90 inches, about 1.4 oz with battery and clip
Compatibility
Uniform and Gear Mounting
-
Works with standard uniform shirt pockets using the pocket clamp slot
-
Works with MOLLE webbing when you position the button between webbing loops
-
Works with thicker mounts up to about 1 inch when you reattach the QuiqClip, including gun belts, citation books, sun visors, jackets, and hats
Surface Attachment
Limitations
-
Not designed for thin, flimsy pocket fabric that cannot support clipped gear
-
USB power source must provide at least 5 volts for proper charging
Intended Users
Law enforcement officers, EMS personnel, firefighters, security teams, and forensic investigators use the QuiqLiteX1 as a hands-free task light. Many users clip it inside a shirt pocket and cover the top with the pocket lapel for a clean, low-profile setup. Others mount it to MOLLE to keep light ready during searches, traffic stops, patient care, or nighttime documentation.
What’s Included
-
1 Quiqlite QuiqLiteX1 Tactical LED Light (MPN QX1RW3)
-
1 Magnetic rotating QuiqClip (removable)
-
1 QuiqLiteX lithium battery, part number 052042
-
1 Type-C USB charging cable
Not included: Wall adapter or external power brick (use any Type-C USB power source that outputs at least 5 volts).
Frequently Asked Questions about QuiqLiteX1
Question 1
How do I wear the QuiqLiteX1 in a shirt pocket?
Remove the QuiqClip by sliding it downward. Clip the light into the shirt pocket fabric between the main body and the pocket clamping slot. Cover the top of the light with the pocket lapel.
Question 2
How do I mount the QuiqLiteX1 to MOLLE webbing?
Remove the QuiqClip by sliding it downward. Position the light so you can access the on and off button between the MOLLE webbing loops.
Question 3
How do tactical mode and boost mode work?
Tactical mode activates when the second press happens within 2 seconds of the first press, letting you turn the colored LED off without toggling past white. Boost mode uses a quick double press to raise output to 150 lumens, then another double press to reduce brightness.
Question 4
What does the low-battery warning look like?
When about 10 percent battery remains, the light flashes quickly two times every two minutes to warn you it needs charging.
Question 5
What do the charging lights mean, and how long does charging take?
A steady red indicator means charging. A flashing red indicator means charged. Charging typically takes about 2 hours and can take up to 2.5 hours or less based on the power source.
